Air-lux - no compromise
air-lux is about high-tech and craftsmanship, air-lux is about creativity and precision. This is how we support architects and advise clients and façade planners. In this way, we contribute to objects that reinterpret living and working with light and space. In Switzerland, in the United Kingdom and around the world.
Sliding door Solutions
Curved Sliding window in large Radius 10m.
Minimum radius in curved solution is R3.5m
Air-sealing concept is forgiving tolerances in curved profiles as well as potential construction sagging way better than any conventional sealing system.
In manual and motorized version possible.
Bi-parting Sliding Window with large panels allowing for a seamless barrier-free exit to a terrace.
Motorization optional in case of panel weight >600kg.
Flush to floor and ceiling in full-glass optic.
Large double slider with flush exit to garden terrace.
Key features include patented air sealing for 100% impermeability, security glass, multipoint locking and mechanical fittings to ensure RC3 security level, manual operation and flush threshold.
Horizontal Sliding panels inward inclined.
Also outward inclination possible in up to 15deg.
Including all standard air-lux features
Corner solution without fix-post necessary.
Tight inter-locking in corner with both sliders in manual or motorized version possible.
Angle optional + - 90deg
Sliding window featuring a nicely integrated fall-barrier in glass on interior side.
Full opening or gap-ventilation are possible.
Descending Windows solutions
Garden pavillion with large descending windows on three sides.
Half-open or full retracted for barrier free access to the garden.
Double air-sealing concept to provide 100% Impermeability.
Guillotine window with motorized upward retracting panels.
All air-lux features to provide full impermeability.
Pivot door solutions
Pivot Door as main entrance to a large Residential villa.
Key features include Double-air sealing for 100% impermeability, security glass, Multipoint locking and mechanical fittings to ensure RC3 level, manual operation and flush threshold.
Double Pivot doors as entrance to showroom garage.
Flush to interior and exterior finish floor levels for barrier free access.
Extra large Pivot door for a commercial entrance.
Custom cladding and fittings in bronze on both sides.
Fully manual operation at the fingertip.
The unique air-lux concept - Sealing with air
100% Impermeability, excellent running characteristics
When they are closed, the air seal ensures a 100% impermeability against driving rain, wind and noise. If open, the window slides open with minimal force and friction less providing excellent running characteristics. Minimal wear and tear supports a long-life service life.
Construction Sagging
The façade of a high-rise building is exposed to enormous wind loads; pressure and suction forces. The membrane function of the air-seal ensures a 100% impermeability even under construction movements. Conventional sealing systems easily fail under such conditions and over time.
Sliding panels up to 25 sqm
Big and Bigger - air-lux can accept very large panel sizes of up to 25m2 in a frameless , floor to ceiling design. At a weight of nearly 2000kg , a slider of this type works much like a glass facade, which can slide away to the side in virtual silence.
Motorization
thanks to the air-seal concept and without the friction of a brush-seals the air-lux panel slides away effortless manually with a weight of up to 600kg. A fully integrated motor-drive is assisting to open and close the slider in higher weights. In case of power-failure the slider can be operated manually.
Security
The highly resistant air-lux construction can be further enhanced with mechanical and electronic components as well as specific glass to a tested and certified RC3 level. A full integration into home automation including access control, alarm systems, lock monitoring and audit trails ensure a high security of the openings.
Functions & Features
The single-button ensures a simple and intuitive operation of each sliding panel. Various additional features such as sun-shading, insect screen, gap ventilation, fall protection and threshold flap are available.
Opening Options
A wide variety of designs are possible including, bi-parting Double-slider, Curved slider, Corner solutions, Inclined panels and Pocket Windows. Air-lux specialists are keen to support the planning process in every step.
